線性導軌是機械行業中的重要組成部分，在機械式的工作中給人們帶來了很大的便利，我們今天要講的是線性導軌和滾珠絲桿區別是什么。

　　Linear guideway is an important part of the machinery industry. It brings great convenience to people in mechanical work. What we want to talk about today is the difference between linear guideway and ball screw.

　　下面講到的是線性導軌和滾珠絲杠的材質分別是什么：

　　First of all, what are the materials of linear guide and ball screw respectively?

　　滾珠絲杠分為軋制絲杠和研磨絲杠，材質不一樣，軋制絲杠螺桿和螺母材質分別是CF53和SNCM220，研磨絲杠螺桿材質有變動，為50CrMo4，螺母與軋制一樣。

　　Ball screw is divided into rolling screw and grinding screw. The material of rolling screw and nut is CF53 and SNCM220 respectively. The material of grinding screw and screw is changed to 50CrMo4. The nut is the same as rolling.

　　滑軌一般用C55，滑塊鉻鉬合金鋼。

　　C55, chromium-molybdenum alloy steel for slides is generally used.

　　各所用材料各有不同，所以才有質量及上的區別。加工工藝是較主要的考慮因素。

　　Different brands use different materials, so there are differences in quality and price. Processing technology is the most important consideration.

　　線性導軌和滾珠絲桿區別很大，行走交叉度是指將導軌用螺栓牢固在基準面上，也因變亂前提的分歧選用的線性導軌也是分歧的。絲桿主要用于一些機床大型設備、雕刻機械等較為普遍，非常方便的把旋轉的運動轉換成直線運動，用起來非常方便，從而減少整個設備在旋轉方面的磨損大大降低;線性導軌使用非常廣泛但種類很多，方型四排高珠導軌用于一些大型機床設備，如平面磨床，切片機、線切割等;絲桿主要用于一些機床大型設備、雕刻機械等較為普遍，非常方便的把旋轉的運動轉換成直線運動，用起來非常方便，從而減少整個設備在旋轉方面的磨損大大降低。

　　Linear guideways differ greatly from ball screw. Traveling intersection degree means that the guideways are bolted firmly on the base plane, and the linear guideways chosen because of the differences in the precondition of disturbance are also different. The screw rod is mainly used in some large machine tools, Engraving Machinery and other relatively common, very convenient to convert the rotating motion into linear motion, which is very convenient to use, thus reducing the wear and tear of the whole equipment in rotating greatly; Linear guideways are widely used, but there are many kinds, square four rows of high bead guideways are used for one. Some large machine tool equipment, such as surface grinder, slicer, wire cutting, etc. Screw rod is mainly used in some large machine tool equipment, Engraving Machinery and other relatively common, very convenient to convert the rotating motion into linear motion, very convenient to use, thus reducing the wear of the whole equipment in rotation greatly.

　　線性導軌精確性的判斷

　　Judgment of the Accuracy of Linear Guideway

　　行走平行度是指將導軌用螺栓固定在基準面上，使滑塊在導軌全長上運行時，滑塊與導軌基準面之間的平行度誤差。高度的成對相互差是指組合在同平面上的各個滑塊的高度尺寸的較大值與較小值之差。不同的設備可選用不同精度的導軌。

　　Walking parallelism refers to the error of parallelism between slider and base plane of guideway when the slider is fixed on the base plane with bolts so that the slider runs on the full length of guideway. The paired difference of height refers to the difference between the maximum and minimum height sizes of the sliders combined on the same plane. Different devices can choose different precision guides.
